型號/Model

HCS100-2007JLM-3.15-2.5

HCS100-2311JLM-3.15-2.5

設備總長/Length

7650mm

設備總寬/Width

2950mm

3300mm

設備總高/Height

2100mm

設備凈重/Net Weight

3400kg

3800kg

裁剪高度/

Cutting Height

7cm

刀盤/Cutter Head

2.5mm

磨刀方式/

Grinding Mode

雙輪對旋式/Double Round Disrotatory

最高機械速度/

Maximum Speed

60m/min

電源/Power Supply

380V 50Hz

氣流量/Air Flow

160L/min

氣壓/Pressure

≥0.5MPa

最大功率/

Maximum Power

30kW

減速機背隙/

Reducer Backlash

0.2°

再覆蓋/Recover

手動式/Manual type

慣量推定/

Inertia Calcuation

固定式/Stationary type

編碼器位數/

Encoder Bits

20位/20-bit

移動控制方式/Moving Control Mode

有線手柄/Cable controller

導軌安裝/Guide

Rail Installation

底板調節式/Adjustable bottom plate

進口/Import

減速機/Reducer

氣動式壓/Pneumatic Disc Locking

X

面向市場/Market-oriented

針織市場/Knitting Market

是否可定制/Customization

X

吸附過床/Adsorption Bed

選配/Optional

是否支持非移動/Whether non-mobile is supported

接口保留/Interface reserved
